ASTERIX Category 021 - ADS-B Target Reports
libasterix - ASTERIX Protocol Library

ADS-B target report processing. More...

Collaboration diagram for ASTERIX Category 021 - ADS-B Target Reports:

Topics

 Data Item I021/008 - Aircraft Operational Status
 Aircraft operational status.
 Data Item I021/010 - Data Source Identifier
 Data source identifier.
 Data Item I021/015 - Service Identification
 Service identification.
 Data Item I021/016 - Service Management
 Service management.
 Data Item I021/020 - Emitter Category
 Emitter category.
 Data Item I021/030 - Time of Day
 Time of day.
 Data Item I021/032 - Time of Day Accuracy
 Time of day accuracy.
 Data Item I021/040 - Target Report Descriptor
 Target report descriptor.
 Data Item I021/040 - Target Report Descriptor (Prior version 0.26)
 Target report descriptor (prior version 0.26).
 Data Item I021/070 - Mode-3/A Code in Octal Representation
 Mode-3/A code in octal representation.
 Data Item I021/071 - Time of Applicability for Position
 Time of applicability for position.
 Data Item I021/072 - Time of Applicability for Velocity
 Time of applicability for velocity.
 Data Item I021/073 - Time of Message Reception for Position
 Time of message reception for position.
 Data Item I021/074 - Time of Message Reception of Position - High Precision
 Time of message reception of position - high precision.
 Data Item I021/075 - Time of Message Reception for Velocity
 Time of message reception for velocity.
 Data Item I021/076 - Time of Message Reception of Velocity - High Precision
 Time of message reception of velocity - high precision.
 Data Item I021/077 - Time of ASTERIX Report Transmission
 Time of ASTERIX report transmission.
 Data Item I021/080 - Target Address
 Target address.
 Data Item I021/090 - Quality Indicators
 Quality indicators.
 Data Item I021/090 - Figure of Merit (Version 0.26)
 Figure of merit (version 0.26).
 Data Item I021/095 - Velocity Accuracy
 Velocity accuracy.
 Data Item I021/110 - Trajectory Intent
 Trajectory intent.
 Data Item I021/130 - Position in WGS84 Coordinates (Ver <= 0.23 and >= 0.27)
 Position in WGS84 coordinates (Ver <= 0.23 and >= 0.27).
 Data Item I021/130 - Position in WGS84 Coordinates (Version 0.24 ~ 0.26)
 Position in WGS84 coordinates (version 0.24 ~ 0.26).
 Data Item I021/131 - High-Resolution Position in WGS-84 Co-ordinates
 High-resolution position in WGS-84 co-ordinates.
 Data Item I021/131 - Signal Amplitude (Version 0.26)
 Signal amplitude (version 0.26).
 Data Item I021/132 - Message Amplitude
 Message amplitude.
 Data Item I021/140 - Geometric Altitude
 Geometric altitude.
 Data Item I021/145 - Flight Level
 Flight level.
 Data Item I021/146 - Selected Altitude
 Selected altitude.
 Data Item I021/148 - Final State Selected Altitude
 Final state selected altitude.
 Data Item I021/150 - Air Speed
 Air speed.
 Data Item I021/151 - True Air Speed
 True air speed.
 Data Item I021/152 - Magnetic Heading
 Magnetic heading.
 Data Item I021/155 - Barometric Vertical Rate
 Barometric vertical rate.
 Data Item I021/157 - Geometric Vertical Rate
 Geometric vertical rate.
 Data Item I021/160 - Airborne Ground Vector
 Airborne ground vector.
 Data Item I021/161 - Track Number
 Track number.
 Data Item I021/165 - Track Angle Rate
 Track angle rate.
 Data Item I021/170 - Target Identification
 Target identification.
 Data Item I021/200 - Target Status
 Target status.
 Data Item I021/200 - Target Status (Prior version 0.26)
 Target status (prior version 0.26).
 Data Item I021/210 - MOPS Version
 MOPS version.
 Data Item I021/210 - Link Technology Indicator (Version 0.26)
 Link technology indicator (version 0.26).
 Data Item I021/220 - Met Information
 Met information.
 Data Item I021/230 - Roll Angle
 Roll angle.
 Data Item I021/250 - Mode S MB Data
 Mode S MB data.
 Data Item I021/271 - Surface Capabilities and Characteristics
 Surface capabilities and characteristics.
 Data Item I021/271 - Surface Capabilities and Characteristics (Version 1.0 ~ 2.1)
 Surface capabilities and characteristics (version 1.0 ~ 2.1).
 Data Item I021/295 - Data Ages
 Ages of the data provided.
 Data Item I021/400 - Receiver ID
 Receiver ID.
 Data Item I021/REF - Reserved Expansion Field
 Reserved expansion field (FRN 48 RE).
 Data Item I021/SPF - Special Purpose Field
 Special purpose field (FRN 49 SP).
 Data Record I021 v0.26 - ADS-B Messages
 Data record for ADS-B messages (v0.26).
 Data Record I021 v2.1 - ADS-B Target Reports
 Data record for ADS-B target reports (v2.1).
 Data Record I021 v2.6 - ADS-B Target Reports
 Data record for ADS-B target reports (v2.6).
 Data Record I021 - ADS-B Target Reports
 Data record for ADS-B target reports.

Detailed Description

ADS-B target report processing.

Overview:
Category 021 defines the structure for the transmission of ADS-B (Automatic Dependent Surveillance - Broadcast) reports.
Data Items:
  • I021/010 Data Source Identification
  • I021/040 Target Report Descriptor
  • I021/161 Track Number
  • I021/015 Service Identification
  • I021/071 Time of Applicability for Position
  • I021/130 Position in WGS-84 Co-ordinates
  • I021/131 Position in WGS-84 Co-ordinates, High Resolution
  • I021/072 Time of Applicability for Velocity
  • I021/150 Air Speed
  • I021/151 True Air Speed
  • I021/080 Target Address
  • I021/073 Time of Message Reception of Position
  • I021/074 Time of Message Reception of Position - High Precision
  • I021/075 Time of Message Reception of Velocity
  • I021/076 Time of Message Reception of Velocity - High Precision
  • I021/140 Geometric Height
  • I021/090 Quality Indicators
  • I021/210 MOPS Version
  • I021/070 Mode 3/A Code
  • I021/230 Roll Angle
  • I021/145 Flight Level
  • I021/152 Magnetic Heading
  • I021/200 Target Status
  • I021/155 Barometric Vertical Rate
  • I021/157 Geometric Vertical Rate
  • I021/160 Airborne Ground Vector
  • I021/165 Track Angle Rate
  • I021/077 Time of Report Transmission
  • I021/170 Target Identification
  • I021/020 Emitter Category
  • I021/220 Met Information
  • I021/146 Selected Altitude
  • I021/148 Final State Selected Altitude
  • I021/110 Trajectory Intent
  • I021/016 Service Management
  • I021/008 Aircraft Operational Status
  • I021/271 Surface Capabilities and Characteristics
  • I021/132 Message Amplitude
  • I021/250 Mode S MB Data
  • I021/260 ACAS Resolution Advisory Report
  • I021/400 Receiver ID
  • I021/295 Data Ages
  • I021/RE Reserved Expansion Field
  • I021/SP Special Purpose Field
User Application Profiles (UAP):
  • CAT021 version 0.23 (including the Thales extension)
  • CAT021 version 0.26
  • CAT021 version 2.1
  • CAT021 version 2.4 (default)
Note
This implementation is backward compatible with CAT021 versions 0.23, 0.26, 2.1, 2.2, 2.3, 2.4, 2.5 and 2.6.
