ASTERIX Category 020 - Multilateration Target Reports

Multilateration target report processing. More...

Collaboration diagram for ASTERIX Category 020 - Multilateration Target Reports:

Topics
	Data Item I020/010 - Data Source Identifier
	Data source identifier.
	Data Item I020/020 - Target Report Descriptor
	Target report descriptor.
	Data Item I020/030 - Warning/Error Conditions
	Warning/Error conditions.
	Data Item I020/041 - Position in WGS84 Coordinates
	Position in WGS84 coordinates.
	Data Item I020/042 - Position in Cartesian Coordinates
	Position in cartesian coordinates.
	Data Item I020/050 - Mode-2 Code in Octal Representation
	Mode-2 code in octal representation.
	Data Item I020/055 - Mode-1 Code in Octal Representation
	Mode-1 code in octal representation.
	Data Item I020/070 - Mode-3/A Code in Octal Representation
	Mode-3/A code in octal representation.
	Data Item I020/090 - Flight Level in Binary Representation
	Flight level in binary representation.
	Data Item I020/100 - Mode-C Code
	Mode-C code.
	Data Item I020/105 - Geometric Height (WGS84)
	Geometric height (WGS84).
	Data Item I020/110 - Measured Height in Local Cartesian Coordinates
	Measured height in local cartesian coordinates.
	Data Item I020/140 - Time of Day
	Time of day.
	Data Item I020/161 - Track Number
	Track number.
	Data Item I020/170 - Track Status
	Track status.
	Data Item I020/202 - Calculated Track Velocity in Cartesian Coordinates
	Calculated track velocity in cartesian coordinates.
	Data Item I020/210 - Calculated Acceleration
	Calculated acceleration.
	Data Item I020/220 - Target Address
	Target address.
	Data Item I020/230 - Communications/ACAS Capability and Flight Status
	Communications/ACAS capability and flight status.
	Data Item I020/245 - Target Identification
	Target identification.
	Data Item I020/250 - Mode S MB Data
	Mode S MB data.
	Data Item I020/400 - Contributing Receivers
	Contributing receivers.
	Data Item I020/500 - Position Accuracy
	Position accuracy.
	Data Item I020/REF - Reserved Expansion Field
	Reserved expansion field (FRN 27 RE).
	Data Item I020/SPF - Special Purpose Field
	Special purpose field (FRN 28 SP).
	Data Record I020 - Multilateration Target Reports
	Data record for multilateration target reports.

Detailed Description

Multilateration target report processing.

Overview:

Category 020 defines the message structure for the transmission of multilateration target reports.

Data Items:

• I020/010 Data Source Identifier
• I020/020 Target Report Descriptor
• I020/030 Warning/Error Conditions
• I020/041 Position in WGS-84 Coordinates
• I020/042 Position in Cartesian Coordinates
• I020/050 Mode-2 Code in Octal Representation
• I020/055 Mode-1 Code in Octal Representation
• I020/070 Mode-3/A Code in Octal Representation
• I020/090 Flight Level in Binary Representation
• I020/100 Mode-C Code
• I020/105 Geometric Height (WGS-84)
• I020/110 Measured Height (Cartesian Coordinates)
• I020/140 Time of Day
• I020/161 Track Number
• I020/170 Track Status
• I020/202 Calculated Track Velocity in Cartesian Coordinates
• I020/210 Calculated Acceleration
• I020/220 Target Address
• I020/230 Comms/ACAS Capability and Flight Status
• I020/245 Target Identification
• I020/250 Mode S MB Data
• I020/260 ACAS Resolution Advisory Report
• I020/300 Vehicle Fleet Identification
• I020/310 Pre-programmed Message
• I020/400 Contributing Receivers
• I020/500 Position Accuracy
• I020/REF Reserved Expansion Field
• I020/SPF Special Purpose Field

Note

This implementation is backward compatible with CAT020 versions 1.7 and 1.8.
