ASTERIX Category 019 - Multilateration System Status Messages

Multilateration system status message processing. More...

Collaboration diagram for ASTERIX Category 019 - Multilateration System Status Messages:

Topics
	Data Item I019/000 - Message Type
	Message type.
	Data Item I019/010 - Data Source Identifier
	Data source identifier.
	Data Item I019/140 - Time of Day
	Time of day.
	Data Item I019/550 - System Status
	System status.
	Data Item I019/551 - Tracking Processor Detailed Status
	Tracking processor detailed status.
	Data Item I019/552 - Remote Sensor Detailed Status
	Remote sensor detailed status.
	Data Item I019/553 - Reference Transponder Detailed Status
	Reference transponder detailed status.
	Data Item I019/600 - Position of MLT System Reference Point
	Position of MLT system reference point.
	Data Item I019/610 - Height of MLT System Reference Point
	Height of MLT system reference point.
	Data Item I019/620 - WGS-84 Undulation
	WGS-84 undulation.
	Data Item I019/REF - Reserved Expansion Field
	Reserved expansion field (FRN 13 RE).
	Data Item I019/SPF - Special Purpose Field
	Special purpose field (FRN 14 SP).

Detailed Description

Multilateration system status message processing.

Overview:

Category 019 defines the message structure for the transmission of multilateration service and system status messages.

Message Types (I019/000):

• 1: Start of Update Cycle
• 2: Periodic Status Message
• 3: Event-triggered Status Message

Data Items:

• I019/000 Message Type
• I019/010 Data Source Identifier
• I019/140 Time of Day
• I019/550 System Status
• I019/551 Tracking Processor Detailed Status
• I019/552 Remote Sensor Detailed Status
• I019/553 Reference Transponder Detailed Status
• I019/600 Position of the MLT System Reference Point
• I019/610 Height of the MLT System Reference Point
• I019/620 WGS-84 Undulation
• I019/REF Reserved Expansion Field
• I019/SPF Special Purpose Field
