ASTERIX Category 016 - Independent Non-Cooperative Surveillance System Configuration Reports

INCS system configuration report processing. More...

Collaboration diagram for ASTERIX Category 016 - Independent Non-Cooperative Surveillance System Configuration Reports:

Topics
	Data Item I016/000 - Message Type
	Message type.
	Data Item I016/010 - Data Source Identifier
	Data source identifier.
	Data Item I016/015 - Service Identification
	Service identification.
	Data Item I016/140 - Time of Day
	Time of day.
	Data Item I016/200 - System Configuration Reporting Period
	System configuration reporting period.
	Data Item I016/300 - Pair Identification
	Pair identification.
	Data Item I016/400 - Position of the System Reference Point
	Position of the system reference point.
	Data Item I016/405 - Height of System Reference Point
	Height of system reference point.
	Data Item I016/410 - Transmitter Properties
	Transmitter properties.
	Data Item I016/420 - Receiver Properties
	Receiver properties.

Detailed Description

INCS system configuration report processing.

Overview:

Category 016 defines the structure for the transmission of reports detailing the configuration of an Independent Non-Cooperative Surveillance (INCS) system. It supplements ASTERIX Category 015 by describing the configuration of the system components (transmitters and receivers) that contributed to an INCS target report.

Message Types (I016/000):

• 1: System Configuration
• 2: Transmitter / Receiver Configuration

Data Items:

• I016/000 Message Type
• I016/010 Data Source Identifier
• I016/015 Service Identification
• I016/140 Time of Day
• I016/200 System Configuration Reporting Period
• I016/300 Pair Identification
• I016/400 Position of the System Reference Point
• I016/405 Height of the System Reference Point
• I016/410 Transmitter Properties
• I016/420 Receiver Properties
• I016/SPF Special Purpose Field
